Panasonic S-3650PF3E - Specifications; Indoor Unit Specifications

11
2-2. Type F3
The refrigerant (R32), which is used in the air conditioner, is a flammable refrigerant. So the
requirements for installation space of appliance are determined according to the refrigerant
charge amount [m
c
] used in the appliance.
Regarding the refrigerant charge amount [m
c
] used in the appliance, refer to the installation
instructions for the outdoor unit.
The minimum indoor floor space compared with the amount of refrigerant is roughly as follows:
Table 1-2
Installation height of Indoor Unit: hinst Indoor Unit Type Density Limit Line
hinst
≥
2.2 m Duct units (Horizontal installation) Line 1
1.8 m
≤
hinst
<
2.2 m Duct units (Horizontal installation) Line 2
hinst
<
1.8 m Duct units (Vertical installation) Line 3
Line 1
In the ceiling
Indoor unit
Indoor unit
Indoor unit
In room
In roomIn room
hinst
≥
2.2 m
1.8 m
≤
hinst
<
2.2 m
0.25 m
≤
hinst
<
1.8 m
In the ceilingFalling ceiling etc
Line 2 Line 3
The minimum indoor floor space compared with the amount of refrigerant is roughly as follows:
Use the graph or Table 2 to determine the minimum indoor floor space.
2.01.51.0
1.22 7.90
0.50.0 3.0 4.02.5 3.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0 8.54.5
0
50
100
150
200
250
300
350
400
500
450
550
[m
c
k( tnuoma egrahc tnaregirfer eht : ]
g
)
Line 3
Line 2
Line 1
[Amin] : minimum indoor floor space (m
2
)
Fig. 2
