Auto External Static Pressure Setting Operation
6. buttons
Keep pressing the
, and
simultaneously for 4 or more seconds.
The “Maintenance func” screen appears on the LCD
display.
7. Press the or button to see each menu.
If you wish to see the next screen instantly, press the
or button.
Select “4. Test run” on the LCD display and press the
button.
The “Test run” screen appears on the LCD display.
Change the display from OFF to ON by pressing the
or button. Then press the button.
The “Maintenance func” screen appears on the LCD
display.
8. Press the
LCD display.
button. “TEST” will be displayed on the
Test run setting mode screen appears on the LCD display.
9. Press the button. Test run will be started.
10. Set the operation mode to “ (MODE FAN)” and fan
speed mode to “ (FAN SPEED)” by pressing the
or button or
or button.
button.
The fan motor will be activated, the auto external static
pressure setting operation and setting-check operation will
be performed for about 3 to 30 minutes.
The fan speed will change automatically while these
operations are in progress. When these operations
completed, “TEST” will be disappeared from the LCD
display.
NOTE:
11. Press the button.
The LCD display will be returned to the initial screen.
NOTE:
The auto external static pressure setting operation
and setting-check operation will not be performed
unless “ (MODE FAN)” and “ (FAN
SPEED)” have been selected.
Failure to set this parameter may result in decreased
airflow and condensation.
Then press the
Maintenance func
Sel.
20:30 (THU)
1. Outdoor unit error data
2. Service contact
3. RC setting mode
4. Test run
Page [ ] Confirm
Maintenance func
Sel.
20:30 (THU)
Page [ ] Confirm
1. Outdoor unit error data
2. Service contact
3. RC setting mode
4. Test run
[ ] Confirm
Test run
Change
20:30 (THU)
Test run
OFF
[ ] Confirm
Test run
Change
20:30 (THU)
Test run
ON
Maintenance func
Sel.
20:30 (THU)
Page [ ] Confirm
1. Outdoor unit error data
2. Service contact
3. RC setting mode
4. Test run
[ ] START
20:30 (THU)
TEST
FAN SPEED
FLAP
20:30 (THU)
COOL
DE
TEST
MO
FAN SPEED
FLAP
TEST
20:30 (THU)
MODE
FAN
FAN SPEED
FLAP
20:30 (THU)
MODE
FAN
20:30 (THU)
[ ]
START
