Model No. : TC-P55ST30 Parts List
Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
1 10030-0061200 BATTERY COVER 1 PAVCA
2 K0RB00600022 SIDE UNIT ASSY 1 PAVCA
3 K2AHYH000043 AC INLET WITH CABLE 1 PAVCA
4 K2CG3YY00060 AC CORD(USA) 1 PAVCA
5 K2KYYYY00150 USB CABLE 1 PAVCA
6 MD55F14A6J PLASMA DISPLAY PANEL 1
7 N2QAYB000571 REMOTE CONTROL 1 PAVCA
8 N5HBZ0000055 WI-LAN MODULE(DONGLE) 1 PAVCA
9 TBL5ZX0042 PEDESTAL STAND 1 PAVCA
10 TESD101 SPRING 1
THEJ036J
SCREW(INL-STA_BRA:1 CON_M-S_UNIT:1 CON_A
-B:9)
11
THEJ036J SCREW(TU:3 CONTACT METAL:18) 21
THEJ036J SCREW(P:7 SS:7 SC:7 SUSD:3) 24
THEJ0409 SCREW 10 chap.3.1. (3)
THEL052Z SCREW 13 chap.3.1. (1)
THTA0419 HOOK SCREW 2
11 TKKC5412-1 3D LED PANEL 1 PAVCA
12 TKKC5413 LED PANEL 1 PAVCA
13 TKKL5493 M8 CAP 4 chap.3.1. (6)
TMME332 CLAMPER 2
TMME332 CLAMPER 6
14 TMXX064 AC CORD CLAMPER A 1
15 TMXX065 AC CORD CLAMPER B 1
16 TMZX5191 STAND BRACKET 1 PAVCA
TPD169487 JOINT 4
TPDX0016-1 JOINT FOR PEDESTAL 2
17 TQB2AA0605-1 INSTRUCTION BOOK (ENG/FRE/SPA) 1 PAVCA
21 TSXM217 CABLE (SU11-SD11) 1
22 TSXM234 CABLE (C33-SS33) 1 PAVCA
23 TSXM238-1 CABLE (C10-C20) 1
24 TSXM240-1 CABLE (C26-C36) 1
25 TSXM287 CABLE (A20-SC20) 1 PAVCA
26 TSXM288 CABLE (C21-A31) 1 PAVCA
27 TSXM289-1 CABLE (C31-A32) 1 PAVCA
31 TXFBL5Z0023 STAND ACCESSORY ASSY(POLES) 1 PAVCA
33 TXFEA02ZSER SPEAKER L ASSY 1 PAVCA
34 TXFEA03ZSER SPEAKER R ASSY 1 PAVCA
35 TXFKP02ZSER SIDE TERMINAL COVER 1 PAVCA
36 TXFKU07ZSER REAR COVER 1 PAVCA
37 TXFKY5Z0061 CABINET ASSY 1 PAVCA
TXJA11PAUU SPEAKER LEAD (A11-SPR/SPL) 1 PAVCA
XTB3+8GFJ SCREW M3 2
XTB4+12GFJ SCREW(CAB-CON_MET:TOP6 SIDE6 BOT7 PW:2) 21
XTB4+12GFJK SCREW(BC:15) 15 chap.3.1. (2)
XTS4+10GFN SCREW 4x10 16
XTV3+10JFJK SCREW(REAR AV:2) 2 chap.3.1. (4)
XTV3+8GFJ SCREW(LED:2) 2
XTV3+8GFJ SCREW(S-PRINT:2 V-PRINT:1) 3
XYN3+F10FJK SCREW(BC-AC_INLET:2) 2 chap.3.1. (5)
XYN3+F8FJ SCREW(A-PRINT:4) 4
XYN3+J10FJ SCREW 9
XYN4+E6FJ SCREW(INLET:1) 1
XYN4+F8FJ SCREW(SC-SUSD:4) 4
XYN5+F12FJ SCREW(STAND_BRKT:10 M8_METAL:8) 18
