TH-103PF10WK/TK/RK
10
4 Specifications
Power Source (WK/RK) 220 V - 240V AC, 50 / 60Hz
Power Source (TK) 220 V - 240 V AC, 50 / 60Hz (single phase)
Power Consumption
Power on 1,500 W
Stand-by condition Save OFF 1.0 W, Save ON 0.9 W
Power off condition 0.5 W
Plasma Display panel Drive method: AC type 103-inch, 16:9 aspect ratio
Screen size 2,269 mm (W) × 1,277 mm (H) × 2,604 mm (diagonal)
(No. of pixels) 2,073,600 (1,920 (W) × 1,080 (H)) [5,760 × 1,080 dots]
Operating condition
Temperature 0 °C - 40 °C
Humidity 20 % - 80 %
Applicable signals
Scanning format
525 (480) / 60i 60p, 625 (575) / 50i 50p, 750 (720) / 60p 50p, 1125 (1080) /
60i 60p 50i 50p 24p 25p 30p 24sF,1250 (1080) / 50i
PC signals VGA, SVGA, XGA, SXGA,
UXGA ..... (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
HDMI A-B TYPE A Connector x 2
COMPONENT / RGB IN Y / G (BNC) with sync 1.0 Vp-p (75-ohm)
P
B
/ B (BNC), P
R
/ R (BNC) 0.7 Vp-p (75-ohm)
AUDIO IN (RCA PIN JACK × 2) 0.5 Vrms (high impedance)
PC IN (HIGH-DENSITY Mini D-SUB 15PIN) Y or G with sync 1.0 Vp-p (75-ohm)
Y or G without sync 0.7 Vp-p (75-ohm)
B / P
B
/ C
B
: 0.7 Vp-p (75-ohm)
R / P
R
/ C
R
: 0.7 Vp-p (75-ohm)
HD / VD: 1.0 - 5.0 Vp-p (high impedance)
AUDIO IN (M3 JACK) 0.5 Vrms (high impedance)
SERIAL EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE
AUDIO OUT RCA PIN JACK × 2 (L / R)
OUTPUT LEVEL : VARIABLE (- - 0 dB)
[INPUT 1 kHz / 0 dB, 10 k-ohm Load]
Accessories Supplied
Remote Control Transmitter EUR7636070R
Batteries R6 Size x 2
Fixing bands TMME203 × 2
Dimensions (W × H × D) 2,414 mm × 1,421 mm × 129 mm (141 mm when including protruding portion of slots)
Mass (weight) approx. 220.0 kg net
Notes:
• Design and specifications are subject to change without notice. Mass and dimensions shown are approximate.
• This equipment complies with standards. AS/NZS60065, CISPRE22 Class-B (TH-103PF10WK)
