119
English
Control terminals
SERIAL IN
External Control Terminal
D-sub 9 Pin:
RS-232C compatible
SERIAL OUT
External Control Terminal
D-sub 9 Pin:
RS-232C compatible
IR IN
Stereo mini jack (M3)
IR OUT
Stereo mini jack (M3)
Sound
Built-in speakers
80 mm × 30 mm × 2 pieces
Audio Output
20 W [10 W + 10 W] (10 % THD)
Remote Control Transmitter
Power source
DC 3 V (battery (AAA/R03/UM4 type) × 2)
Operating range
Approx. 7 m (22.9 ft)
(when operated directly in front of remote control
sensor)
Mass
Approx. 63
/ 2.22 oz (including batteries)
Dimensions (W × H × D)
44 mm × 105 mm × 20.5 mm /
1.74” × 4.14” × 0.81”
*
1: Environmental temperature to use this unit at high
altitudes (1 400 m (4 593 ft) and higher and below
2 800 m (9 186 ft) above sea level): 0 °C to 35 °C
(32 °F to 95 °F)
*
2: VIERA LINK is not supported.
Note
●
Design and specifications are subject to change
without notice. Mass and dimensions shown are
approximate.
