Assembling the pedestal
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way
when using the wall-hanging bracket or repacking the
TV.
1 Put the TV onto a work table with the screen panel
down on the clean and soft cloth.
2 Remove the assembly screws
from the TV.
3 Pull out the pedestal from the TV.
4 Remove the assembly screws
from the bracket.
To Next Page
