Technical Information
43
PC connection
A PC may be connected to this TV so that the PC screen is displayed and sound is heard from the TV.
●
PC signals that can be inputted: Horizontal scanning frequency 31 to 69 kHz; vertical scanning frequency 59 to
86 Hz (more than 1,024 signal lines could result in incorrect display of the image).
●
A PC adaptor is not necessary for the DOS/V-compliant D-sub 15-pin connector.
Note
●
Some PC models cannot be connected to this TV.
●
When using PC, set the colour display quality of PC to the highest position.
●
For details of the applicable PC signals “Input signal that can be displayed” (p. 45)
●
Maximum display resolution
Aspect
4:3 1,440 × 1,080 pixels
16:9 1,920 × 1,080 pixels
●
D-sub 15-pin connector signal
Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name
R GND (Ground) NC (not connected)
G GND (Ground) NC (not connected)
B GND (Ground) HD
NC (not connected) NC (not connected) VD
GND (Ground) GND (Ground) NC (not connected)
USB connection
●
It is recommended to connect the USB Flash Memory directly to the TV’s USB port.
●
Some USB devices or USB HUB may not be used with this TV.
●
You cannot connect any devices by using USB card reader.
●
Additional information for USB devices may be on the following website. (English only)
http://panasonic.jp/support/global/cs/tv/
