Panasonic Viera TX-P42U20B - HDMI Equipment Connections; HDMI connection details; Headphone connection and volume; Ferrite core installation

External Equipment ●
Advanced
63
DVD Recorder
HDMI equipment
Fully wired HDMI
compliant cable
Terrestrial
aerial
RF cable
DVD Recorder /
VCR
To record /
playback
“HDMI connection” (p. 67)
or
Rear of the TV
COMPONENT
P B
Y
P R
R
L
AUDIO OUT
R
L
DIGITAL AUDIO OUT
12
∗
1
Headphones
To adjust volume●
“Headphone Volume” in
the Sound Menu (p. 29)
(M3 stereo
mini plug)
Ferrite core (supplied)
Less than
10 cm
Installing the Ferrite core
Pull back the tabs
(in two places)
Wind the cable
twice
Open
Press the cable
through and close
