Preparation
14
Monitor display (Sub monitor station)
The following display is an example for description purposes, and it may differ from the actual display.
LThe monitor display is turned off during standby. When you press {OFF}, the information display appears.
A Indicates the battery level.
Estimated operating time after charging
the battery for 7 hours.
(When surrounding temperature is 20 °C.)
LContinuous operating time:
Approx. 2.5 hours
LStandby time: Approx. 200 hours
( When the sub monitor station is off
the charger and is not in use after the
battery is fully charged.)
• 
While “OUT OF RANGE” is displayed
(page 15), the standby time is shortened.
Recharge the battery immediately.
L2 beeps sound every
4 seconds and a call
is disconnected within
about 60 seconds.
L“RECHARGE BATTERY” is
displayed.
(The battery needs to be recharged.)
While
in use
During
standby
( ashing)
B Indicates which door station is calling, monitoring,
or in a call. Also indicates which door station took
the image while viewing it.
(Example)
Door station 1
C Indicates which door station is calling while talking
or monitoring.
(Example)
Door station 2
D Indicates that the door is opened when the door
opener (sold separately) is connected to the main
monitor station (page 20).
E Indicates that the “Press-to-talk” mode is on
(page 20).
F Indicates the voice changer mode is on (page 19).
VL-GM002
{OFF}
Navigator key
H
I
K
L
A B C D E GF
J
