Panduit R4PFP User Manual

6”
Installation Instructions-Orientation of Hardware with 6” Spacing Between Racks
Installation Instructions-Hardware Mounting Method
INSTRUCTIONS CM439B
For Technical Support: www.panduit.com/resources/install_maintain.asp
Page 2 of 4
Outside of panels
Outside of panels
Inside of panels
Inside of panels
1/4-20 Screws
Must be through
(2) panels
1/4-20 Screws
Must be through
(2) panels
1/4-20 Standard Nuts
Fastened to Screws
1/4-20 Weld Nuts
Fastened to
Screws
Top View
Top View
Bottom Center
View
Top Center
View
Center View
Top Center View
Center View
Bottom Center View
Bottom View
Bottom View
(2) 1/4-20 Screws and
(2) 1/4-20 Standard
Nuts
(2) 1/4-20 Screws and
(2) 1/4-20 Standard
Nuts
(4) 1/4-20 Screws and
(2) 1/4-20 Weld Nuts

Panduit R4PFP Specifications

General

Brand	Panduit
Model	R4PFP
Category	Industrial Equipment
Language	English
