Final Assembly
1 300521-1 Base Weldment
2 800746-1 Outer Post Assembly
3 800747-1 Overhead Chassis
4 800758-1 Rotating Arm Assembly
5 1-418821 Tubehead/Yoke Assembly
6 800732-1 Film Drum Shield Assembly
7 800725-1 Chinrest Arm Assembly
8 2-419340 Head Support Assembly
9 800735-1 Control Panel Assembly, PC-1000
10 800735-2 Control Panel Assembly, Laser 1000
11 800749-1 Electronics Assembly
12 800741 Screw Motor Assembly
13 800655-1 Belt Drive Assembly
14 800752-1 Electromagnet Assembly, Laser 1000
15 300336-1 Top Cover
16 800705-2 Rear Cover
17 800701 Side Cover, Non-Control Panel
18 800704-1 Side Cover, Control Panel
19 1-229060 Cover, Inertia Wheel
20 1-50362 Mounting Bolt, 1/4-20X1/2" Long
21 1-133394 Hex Post (Standoff)
22 29-318027 PHMS 4-40 1 1/4" Long
23 1-317968 Holder, Exposure Switch
24 1-229983 Decal, Model
25 1-229548 Decal, USA Flag
26 1-229916 Decal, Right Arrow
27 2-229916 Decal, Left Arrow
28 800733-1 Film Drum Assembly
29 300533-1 Decal, Warning
