Film Drum Assembly
1 93-318027 PHMS 8-32X3/8 SS
2 4-50622 Washer #8
3 1-317942 Plate Assembly, Film Drum
4 2-317900 Slot Plate Support
5 266-507252 Set Screw 5/16-18 7/16" LG
6 1-131729 Spacer, Film Drum
7 1-133454 Plug, Push In
9 300454 Film Drum
10 1-133579 Velcro Hook Side, End
11 1-133579 Velcro Hook Side, Shaft
12 300467-1 Knob, Film Drum
13 12-50621 Washer 9/16"
14 1-229117 Nut, Special
15 226-50752 Set Screw #6-32X7/16L Hex
16 300455-1 Pointer, Film Drum
17 229988-5 BHMS #6-32X1/2
18 300461-1 Decal, Pointer Alignment
