Upper Belt Drive Assembly
1 300333-1 Machine Casting, Upper Drive
3 229063-1 Bearing, Needle Roller
4 1-317910 Shaft, Wheel
5 235-50752 Set Screw 8-32 3/8 SHCP
6 1-317911 Shaft, Wheel Plain Head
8 229576-1 Roller Assembly
9 7-52482 Ring, Retaining
10 800683-1 Drive Motor Assembly
11 550002-23 #10-32X1/2 SOC HD CAP Screw
12 5-50622 Washer, Flat #10
13 10-50642 Lockwasher, Split #10
14 550003 #10-32X1-3/4 SHCS Full Thread
G
To Next Page
