Appendix
© Copyright 2008 Panoramic Corporation
Belt Drive Assembly
1 800642-1 Upper Belt Drive Assembly
3 300543-1 Holder, Cam
4 1-317940 Rod, Guide Center
5 1-229305 Rod, Guide Top
6 300323 Bracket, Micro Switch
10 1-229303 Block Mounting Rod Support
11 800642-1 Upper Belt Drive Assembly
13 26-318027 Screw P.H. 4-40 3/4: Long
14 98-318027 #8-32X1 Pan Hd PHL SS
15 19-52752 S.H.C 8-32 3/4" Long
17 4-50642 Split Lockwasher #4
18 300529-1 Nut Plate
19 229090-1 Micro Switch
20 03-50622 Washer, Flat #6
22 2-50622 Washer, Flat #4
23 60-318027 P.H.S. 6-32 1/2" Long
24 8-50642 Split Lockwasher #8
27 317909-3 Lower Drive Assembly
31 6-50642 Lockwasher, Split #6
32 300321-1 Shaft, Cam Mounting
33 79-52901 Pin, Roll 3/16 Dia 1/2" Lg
34 1-318680 Cam, Upper Drive
35 2-229171 Washer, Thrust
36 2-229066 Thrust-Needle Bearing
39 1-131773 Key, Upper Drive Shaft
40 300328 Driven Pulley
41 1-131708 Nut, Hex Spc 3/4-10
42 243-50752 Set Scr 10-24 1/4" S.H.
43 300326 Actuator, Switch
44 95-318027 P.H.S. 8-32 5/8" Long
45 300331 V-Belt, Drive
46 300327-1 Pulley, Motor Drive
47 52-50720 1/4-20X1/4 Soc Set Cup
48 14-50622 Washer, Flat, 3/4 Std
49 550002-22 10-32X3/8 SHCS B.B.
