Appendix
© Copyright 2008 Panoramic Corporation
Roller Orbit Drive Assembly
1 229081-1 Plate, Shaft & Bearing Mounting
2 1-229079 Open Block, Bearing
3 229080-3 Block, Brg Retainer
4 1-229065 Bearing, Self Aligning
5 17-52922 Ring, Retaining
6 1-229083 Shaft, Wheel Drive
7 1-229082 Roller, Orbit Driving
8 40-50721 Set Scr 10-24X3/16 Lg
9 229098-1 Washer, Special Plastic
10 110-318027 Scr 10-32X1/2" Lg
11 10-50642 Lockwasher, Split #10
12 1-229097 Inner Race, Needle Rl Brg
13 229063-3 Bearing, Roller
14 1-131704 Roller, Wheel Drive
15 1-50721 Set Scr 4-40X1/8" Lg
16 03-50622 Washer, Flat #6
17 550015-62 Screw, Ph Phil, #6-32X3/4
18 6-50642 Lockwasher, Split #6
19 3-50212 Nut, Hex #6-32
20 542004-0209 Shim, .010THK, .5ID, .75OD
21 542004-0211 Shim, .015THK, .5ID, .75OD
22 542004-0212 Shim, .020THK, .5ID, .75OD
