Electronics Assembly
1 300496-1 Plate, Electronics Controller
2 800751-1 PCB Assembly, Transformer Power Supply
3 800750 PCB Assembly, X-ray Controller
4 225470-2 PCB Standoff 0.010
5 594002 Relay, 12VDC, 25-30A, SPST
6 594003-2 Relay, 12VDC, 10A, 3PDT
7 594003-1 Relay, 12VCD, 10A, SPDT
8 3-131747 Resistor, 75 Ohm, 50W, WW Var
9 2-131747 Resistor, 100 Ohm, 50W, WW Var
10 1-131748 Resistor, 5 Ohm, 25W
11 1-229174 Rheostat
12 1-131787 Knob, Rheostat
13 542006-14 Spacer, #6X1/2 Round
14 5-226396 Diode, 40HF10
