Appendix
© Copyright 2008 Panoramic Corporation
Control Panel Assembly
1 800730-1 Control Panel Weldment
2 800689-200 60-120 VAC Meter/PCB Assembly
3 300465-1 Knob, kVp Adjust
4 300463-1 Knob, Function Switch
5 2-131779 Fuseholder
6 4-131781 Fuse, 10A
7 3-131781 Fuse, 1A
8 318557-1 Exposure Cord/Switch Assembly
9 1-229192 Switch, Pushbutton
10 1-131772 Cap, Pushbutton Switch
11 1-229310 Housing-Switch, Top
12 1-229311 Housing-Switch, Bottom
13 2-131785 Bushing, Strain Relief
14 229990-1 Cable Spiral Assembly
15 1-229941 Indicator, Red
16 1-229940 Switch, Reset, Blue
17 2-229940 Switch, Main, Yellow
18 300460-1 Decal, Control Panel, PC-1000
19 300460-2 Decal, Control Panel, Laser 1000
20 1-229184 Relay, Power
21 800736-1 Timer/Rotary Switch Assembly
22 800768-1 Transformer Assembly
G
