Laser Collimator Assembly
1 800757-1 Shell Assembly, Collimator
2 300504-1 Guide Rail, Top
3 300505-1 Guide Rail, Bottom
4 800756-1 Aperture Plate Assembly
5 28-318028 FHPS 4-40X1
6 26-318027 Screw PH 4-40 3/4 Long
7 800760-1 Laser Lens Assembly
8 02-52750 SHCS 4-40X3/8
9 600500 Snap Button, F-Flat Type
10 4-50642 Split Lockwasher #4
11 21-318027 PHMS, 4-40 1/4" Long
12 300508-1 Switch, Subminature
13 172-318027 PHMS #2-56X0.50
14 542006-2 Spacer
15 800720-1 PCB Assembly, Ceph Laser
16 2-50212 Hex Nut #4-40
