Sound Shower AA-160e / AA-160mm Operation Manual v.2.0 26.3.2012 ©
Panphonics Oy 4/7
If the settings should be permanent (even during the power failure), use the ‘amb
save’ –command to save the settings.
&
amb#save#
Save&ambient&control&parameters&to&Flash&memory&
Usage:&amb&save&
Output:&OK&
&
If it’s needed to restore the factory parameter settings for the Ambient Control), use
the ‘amb factory’ –command.
&
&
amb#factory#
Restore&Ambient&Control&factory&settings&and&store&parameters&to&Flash&memory&
Usage:&amb&factory&
Output:&OK&
Changing input sensitivity with ‘PRE’-setting
The current input sensitivity setting can be checked with ‘PREREAD’ –command
(default = 10). The sensitivity can be changed by commanding ‘PRE00‘– ‘PRE20’. The
minimum is ‘PRE00’ which corresponds the amplitude 1:1 and the maximum is
‘VOL20’ and it corresponds +20dB amplitude. Changing the PRE-setting affects to the
actual sound pressure level as is presented in the following table.
RCA Input
PRE
Max in Vp-p
Output Vp-p
SPL@1m
0
> 4
218
104
10
1.32
218
105
15
0.8
234
106
20
0.45
236
104
XLR Input
0
> 4
190
102
05
2.50
220
103
10
1.60
248
106
15
0.78
200
103
20
0.45
202
106
Any value between the 00 and 20 can be given. If the setting should be permanent
(even during the power failure), use the ‘PRESAVE’ –command to save the setting.
PREREAD#
Read&current&volume&setting&from&the&unit&
Usage:&PREREAD&
Output:&PRE=22&
&
PRExx#
Set&input&sensitivity&PRE00^VOL37&(default&=&10)&
Usage:&VOL15&
Output:&STATUS00,ON&
PRESAVE#
Save&input&sensitivity&setting&to&Flash&memory&
Usage:&PRESAVE&
Output:&OK&
