16
Design
Crossover(s)
High-Frequency Driver(s)
Bass / Midrange Driver(s)
Bass Driver(s)
Low-Frequency Extension*
Frequency Response:
On-Axis
30˚ Off-Axis
Sensitivity – Room / Anechoic
Suitable Amplifier Power Range
Maximum Input Power
†
Impedance
Dimensions (h x w x d)
Weight (unpacked)
Finishes
5-driver, 2-1/2-way LCR, acoustic
suspension, on-wall with option to
mount center configuration on
table or shelf
2nd-order electro-acoustic at 2.1
kHz; 2nd-order electro-acoustic
a
t 500 Hz (bass drivers)
25-mm (1 in) S-PAL
™
satin-
anodized pure-aluminum dome,
ferro-fluid damped and cooled
Two 90-mm (3-1/2 in) mineral-
filled polypropylene cones, 25-mm
(1 in) high- temperature voice coil,
oversize ceramic / ferrite magnets
Two 90-mm (3-1/2 in) mineral-
filled polypropylene cones, 25-mm
(1 in) high- temperature voice coil,
oversize ceramic / ferrite magnets
75 Hz (DIN)
±2 dB from 115 Hz – 20 kHz
±2 dB from 115 Hz – 15 kHz
95 dB / 92 dB
15 – 200 watts
100 watts
Compatible with 8 ohms
67.0 cm x 16.1 cm x 10.4 cm
26-3/8 in x 6-5/16 in x 4-1/16 in
5.8 kg / 12.8 lb per speaker
Black Gloss
CINEMA
™
400 CINEMA
™
TRIO
All-in-one left / right / center:
7-driver, 3-channel, 2-way,
acoustic suspension
2nd-order electro-acoustic
at 1.8 kHz
Three 25-mm (1 in) S-PAL
™
satin-
anodized pure-aluminum domes,
ferro-fluid damped and cooled
Four 90-mm (3-1/2 in) mineral-
filled polypropylene cones, 25-mm
(1 in) high- temperature voice coil,
oversize ceramic / ferrite magnets
n/a
85 Hz (DIN)
±2 dB from 125 Hz – 20 kHz
±2 dB from 125 Hz – 15 kHz
89 dB / 86 dB
15 – 150 watts
70 watts per channel
Compatible with 8 ohms
16.1 cm x 91.5 cm x 10.4 cm
6-5/16 in x 36 in x 4-1/16 in
7.6 kg / 16.8 lb per speaker
Black Gloss
*
DIN 45 500 Indicates -3 dB in a typical listening room.
†
With typical program source, provided the amplifier clips no more than 10% of the time.
