WALL MOUNTING
3.258"
If you are not comfortable performing the following procedures, have a professional perform
the installation (see your Authorized Paradigm
®
Dealer about hiring a professional).
TOLERANCE UNLESS OTHERWISE SPECIFIED
5
Step 3Step 2
Step 1
CINEMA
™
100
Assemble all parts before moving to Step 3
Attach bracket to wall
(screws not supplied)
Vertical:
Speakers tilt left/right
to further improve
stereo imaging
Horizontal:
Speaker tilt up/down
for optimal dialog clarity
Do not tighten completely
with allen key until
you adjust for
desired angle
