Sicherheitshinweise • Safety instrucons
Screw anchor pull-out forces
Pull-out forces state the force required for
pulling a screw out of the wall. No dierence
is made between the screw plus screw an-
chor coming out of the wall, the screw brea-
king or the brickwork failing.
The pull-out forces state the maximum ten-
sile force that may be exerted on the screw
and/or screw anchor.
The xing material must be selected to
match the ng base, type of ng and
pull-out forces.
The values in the table are stated in kN and
express the pull-out force of the anchor
(screw / screw anchor) which is subjected to
the highest tension.
The values are calculated for an anchor in
unbroken concrete.
The selecon of the most suitable xing ma-
terial depends on the type of ng base and
its physical condion. The er is responsib-
le for checking the ng base prior to ng
the awning.
The screw anchor pull-out forces are calcu-
lated on the basis of Wind Resistance Class
1 in accordance with the EN 13561 and EN
1932 standards.
Size from
N/Console number
Wall Ceiling
250 cm x 150 cm 821/2 1232/2
300 cm x 250 cm 2734/2 4101/2
350 cm x 300 cm 3061/3 4592/3
400 cm x 300 cm 3500/3 5250/3
450 cm x 350 cm 4019/4 6029/4
500 cm x 350 cm 4467/4 6701/4
550 cm x 350 cm 4913/4 7370/4
600 cm x 350 cm 5358/4 8037/4
