Park Central Arch - Arch Frame Footing Layouts (5)

SWING FRAMES
DATE: 08/29/2014
INSTALLATION GUIDELINES
Page 5 of 20
FOOTING LAYOUT - 5” ARCH FRAME - ONE BAY
FOOTING LAYOUT - 5” ARCH FRAME - TWO BAY
FOOTING LAYOUT - 5” ARCH FRAME - THREE BAY
FOOTING LAYOUT - 5” ARCH FRAME - FOUR BAY
48”
48”
48”
48”
