PDSSAP 20-Li B3
GB
│
MT
│
45 ■
Torque levels 1st level 120 Nm
2nd level 150 Nm
3rd level 190 Nm
4rd level 226 Nm
Max. screw capacity M16
Tool holder 1/4" hexagon socket
PAP 20 B3* battery
Type LITHIUM ION
Rated voltage 20 V
(DC)
Capacity 4 Ah
Cells 10 (80 Wh)
High-speed battery charger PLG 20 C3*
INPUT
Rated voltage 230–240 V ∼ 50 Hz
(AC)
Rated power
consumption 120 W
Fuse (internal) 3.15 A
T3.15A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 4.5 A
Charging time approx. 60min
Protection class II /
(double insulation)
* BATTERY AND CHARGER ARE NOT SUPPLIED
Noise emission value
Noise measurement value determined in accord-
ance with EN 62841. The A-rated noise level of
the power tool is typically as follows:
Sound pressure level L
PA
= 85.4 dB (A)
Uncertainty K
PA
= 3 dB
Sound power level: L
WA
= 96.4 dB (A)
Uncertainty K
WA
= 3 dB
Vibration emission value
Total vibration values (vector total of three direc-
tions) determined in accordance with EN 62841:
Tightening screws and nuts of maximum permissible
size a
h
= 9.598 m/s
2
Uncertainty K = 1.5 m/s
2
Wear ear muffs!
NOTE
► The vibration emission values and the noise
emission values given in these instructions have
been measured in accordance with a standard-
ised test procedure and can be used for
comparison of the power tool with another tool.
► The specified total vibration values and the
noise emission values can also be used to
make a provisional load estimate.
WARNING!
► Depending on the manner in which the
power tool is being used, and in particular
the kind of workpiece being worked, the
vibration and noise emission values can
deviate from the values given in these instruc-
tions during actual use of the power tool.
► Try to keep the vibration load as low as
possible. Measures to reduce the vibration
load are, e.g. wearing gloves and limiting the
working time. Wherein all states of operation
must be included (e.g. times when the power
tool is switched off and times where the power
tool is switched on but running without load).
