1 Bag with spare parts:
1 Sealant ring on shut-off valve
(22.5mm)**
1 Spring gasket on shut-off valve
(12mm)**
1 Sealant ring inside the nut of shut-off
valve (19mm)**
1 Sealant ring inside the mist nozzle
(19.5mm)**
1 Sealant ring inside the fan nozzle
(16mm)**
1 Sealant ring inside the cone spray
head (9.3mm)**
3 Sealant rings on plastic nozzle
pipe and stainless steel nozzle pipe
(14.2mm)**
1 Instruction manual
Parts description
Fig. A:
[1] Handle
[2] Hose
[3] Spray tank
[4] Volume scale
[5] Battery compartment cover
[6] Shoulder strap
[] Strap hook ×4
[7] Spray tank pin
[8] Spray tank cover
[9] Stainless steel nozzle pipe
[] Plastic nozzle pipe
[] Hanging hook
[] Nozzle accessories:
Fan nozzle ×1
Double head nozzle ×1
Single head nozzle ×1
Mist nozzle ×1
Fig.B:
[] Pressure display
[] Power button
[] Charge level indicator
[] Pressure selection button
[] Connection status LED
Fig.C:
[] Battery pack*
[] Release button
[]
button (charging level)
[] Battery level indicator
[] Power cord with power plug
[] Battery charger (rapid battery charger)*
[] Charging control LED – red
[] Charging control LED – green
Fig. E to P:
[] Basket filter
[] Eyelets ×4
[] Trigger
[] Union nut ×2
[] Security ring ×2
[] O-Ring ×2
[] Pipe nut
[] Cone spray head
[] Battery connector
[] Lock-on latch
[] Small filter
[] Shut-off valve
* Battery pack and rapid battery charger are
not included.
** Outer diameter
