Park Tool Co.
5115 Hadley Ave. N., St. Paul, MN 55128 (USA) www.parktool.com
PRS-25 Team Issue
Portable Repair Stand
Part No. Description
Qty.
1932 Upright Tube 1
1927 Upright End Cap 1
1929-1 Yoke Sleeve 1
1930 Yo ke 1
1922-2 Leg Tube 2
1924-3 Leg and Yoke Spacer 3
1925-2 Leg Strap 2
1920L Left Leg Cap 1
1920R Right Leg Cap 1
1933 Collar 1
1934 Extension Tube 1
1935A Top Tube Assembly 1
100-25D Clamp Assembly 1
1923-4 Leg Screw 4
1928-2 Button Head Cap Screw, M6 x 1.0 2
1929-2 Button Head Cap Screw, M5 x 0.8 1
1931 Yoke Quick Release 1
944B Hex Nut, M5 x 0.8 1
1926-4 Washer 4
1883-4 Nylok Nut, M6 x 1.0 4
1921-2 Leg End Cap Screw 2
34
35
36
37
38
39
40
41
42
32
43
33
31
29
30
28
26
27
25
24
23
34
35
33
32
23
39
38
37
25
40
29
24
37
36
28
31
43
42
41
3027
26
©2013 Park Tool Co. / PARK TOOL® and the color BLUE are registered trademarks of Park Tool Co. 11/13
