WAG-4 PART NUMBERS
WAG-4 Parts / Pièces / Teile / Partes
© 2018 Park Tool Co.
PARK TOOL® and the color BLUE are registered trademarks of Park Tool Co.
08/18
Ref. # Part # Description Qty.
1 1111 Assembly Screw
5
2 1120 Body
1
3 1121 Gauge Block
1
4 1127 Gauge Spring
1
5 1126 Gauge Washer
1
6 1125 Gauge
1
Ref. # Part # Description Qty.
7 1124 Gauge Knob
1
8 1122-2 Foot
2
9 1123-2 Sliding Block
2
10 1129-2 Sliding Block Plunger
2
11 1130 -2 Sliding Block Set Screw
2
1
2
3 4
Contact
Contact
Contact
Contact
Contact Contact
Contact
Contact
Gap
Gap Gap
Contact
