Parrot Disco FPV User Manual

ENGLISH
27
LOSS OF CONNECTION
If the connection is lost during flight between your Parrot
Skycontroller 2 and your Parrot Disco, the Parrot Disco will fly in
60-meter diameter circles for a specified time period (10 seconds
by default).
If the connection is not restored, the Parrot Disco returns to its
starting position and then flies in 60-meter diameter circles.
If the connection is not restored after 5 minutes, the Parrot Disco
performs a circular landing.
TURNING OFF THE PARROT DISCO
To turn off the Parrot Disco, press and hold down the On/Off button.
> The red light flashes, and then the Parrot Disco turns off.
RETRIEVING YOUR PHOTOS
AND VIDEOS
ON YOUR COMPUTER
Always use the micro USB port to the left of the Parrot C.H.U.C.K.
1. Connect the Parrot Disco to your computer with the USB/micro
USB (provided).

Parrot Disco FPV Specifications

General

Product color	Black, White
Housing material	Carbon, Expanded polypropylene (EPP)
Maximum speed	22 m/s
Frequency band	2.4/5 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	1 rotors
Maximum weight capacity	- kg
Maximum operating distance	2000 m
Supported video modes	1080p
Maximum video resolution	1920 x 1080 pixels
Operating time	45 min
Battery capacity	2700 mAh
Cables included	USB
Moving control functions	-

Weight and Dimensions

Depth	580 mm
Width	1150 mm
Height	120 mm
Weight	750 g
