Parrot Disco FPV User Manual

ENGLISH
29
VIA A MICRO USB FLASH DRIVE
1. Connect your micro USB flash drive (not provided) to a computer.
Make sure that your flash drive does not contain any files in .plf
format.
2. Go to the Parrot Disco’s support page on www.parrot.com and
download the update file available in .plf format.
3. Copy this file to the root of your micro USB flash drive.
4. Turn on the Parrot Disco.
5. Connect the micro USB flash drive to one of the Parrot Disco’s
ports.
> The Parrot Disco automatically restarts and the warning light
flashes yellow. Then, the Parrot Disco restarts again.
6. Wait until the Parrot Disco has completely restarted.
7. Disconnect the micro USB flash drive.
> The update is complete. Make sure the new version has actually
been installed: in the FreeFlight Pro application, go to Menu >
Settings. The version number is shown in the general information.
WARNING LIGHT INDICATIONS
Flashing
red light
The Parrot Disco is starting up�
Or
The Parrot Disco has detected an error�
> Restart the Parrot Disco on a flat,
immobile surface, out of the wind. If the
problem persists, visit the Parrot Disco’s
support page on www.parrot.com.
Flashing
green light
The Parrot Disco has detected the GPS signal
and is ready to take off�
Flashing
yellow light
The Parrot Disco update is underway�
Do not turn off the Parrot Disco�

Parrot Disco FPV Specifications

General

Product color	Black, White
Housing material	Carbon, Expanded polypropylene (EPP)
Maximum speed	22 m/s
Frequency band	2.4/5 GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	1 rotors
Maximum weight capacity	- kg
Maximum operating distance	2000 m
Supported video modes	1080p
Maximum video resolution	1920 x 1080 pixels
Operating time	45 min
Battery capacity	2700 mAh
Cables included	USB
Moving control functions	-

Weight and Dimensions

Depth	580 mm
Width	1150 mm
Height	120 mm
Weight	750 g
