PCB Piezotronics 394C06 - Page 9

Model Number
394C06
HAND HELD SHAKER
Revision: H
ECN #: 40107
[12]
Performance
ENGLISH
SI
Operating Frequency(± 1 %) 159.2 Hz 159.2 Hz
Acceleration Output(± 3 %) 1.00 g rms 9.81 m/s² rms
[6]
Velocity Output 0.39 in/sec rms 9.81 mm/s rms
[7]
Displacement Output 0.39 mil rms 9.81 µm rms
[7]
Transverse Output ≤ 3 % ≤ 3 %
Distortion(0 to 99 grams load) ≤ 2 % ≤ 2 %
Distortion(100 to 149 grams load) ≤ 5 % ≤ 5 %
Distortion(150 to 210 grams load) ≤ 9 % ≤ 9 %
Maximum Load 7.4 oz 210 gm
[8]
Automatic Switch Off Time 1.0 to 2.5 minutes 1.0 to 2.5 minutes
[9]
Calibration Cycles(2 gram load) 320 cycles 320 cycles
[5]
Calibration Cycles(25 gram load) 600 cycles 600 cycles
[5]
Calibration Cycles(50 gram load) 1600 cycles 1600 cycles
[5]
Calibration Cycles(100 gram load) 400 cycles 400 cycles
[5]
Calibration Cycles(150 gram load) 160 cycles 160 cycles
[5]
Calibration Cycles(210 gram load) 80 cycles 80 cycles
[5]
Environmental
Temperature Range(Operating) +15 to +130 °F -10 to +55 °C
Electrical
Ramp-Up time ≤ 3 sec ≤ 3 sec
[1]
Internal Battery(Quantity) 4 4
Internal Battery(Type) AA AA
[2]
DC Power 10 VDC 10 VDC
[3]
DC Power 2.4 amps 2.4 amps
[4][3]
Battery Life(2 gram load) 8 hours 8 hours
[5]
Battery Life(25 gram load) 15 hours 15 hours
[5]
Battery Life(50 gram load) 40 hours 40 hours
[5]
Battery Life(100 gram load) 10 hours 10 hours
[5]
Battery Life(150 gram load) 4 hours 4 hours
[5]
Battery Life(210 gram load) 2 hours 2 hours
[5]
Physical
Size (Diameter x Height) 2.2 in x 7.8 in 56 mm x 200 mm
Weight(with batteries) 31 oz 900 gm
[1]
Mounting Thread 10-32 Female 10-32 Female
[10][11]
Mounting Torque(Maximum) 10 in-lb 112 N-cm
[11]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
ICP
®
is a registered trademark of PCB Group, Inc.
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
M
- Metric Mount
Acceleration Output(± 3 %) 1.02 g rms 10.0 m/s² rms
NOTES:
[1]
Typical.
[2]
Alkaline type recommended for longest service life.
[3]
This specification for external DC power supply (optional).
[4]
Maximum.
[5]
Approximate values, based on automatic switch off time and dependent on type of batteries.
[6]
Unit supplied set to rms; see manual for peak selection.
[7]
Calculated values for reference only.
[8] Maximum load includes sensor, connector and cabling.
[9]
Unit supplied set to auto shut off; see manual for continuous use selection.
[10]
Test sensor should be hand tightened (without tools).
[11]
Transducer to shaker table.
[12]
See PCB Declaration of Conformance PS022 for details.
SUPPLIED ACCESSORIES:
Model 073A15 Battery Pack (1)
Model 080A109 Petro Wax (1)
Model 080A84 Mounting Base (5-40 to 10-32) (1)
Model 080A85 Mounting Base (M3 X 0.5 to 10-32) (1)
Model 081A08 Mounting Stud (10-32 to 1/4-28) (1)
Model 081B05 Mounting Stud (10-32 to 10-32) (2)
Model M081B05 Mounting Stud 10-32 to M6 X 0.75 (1)
Model M081B23 Metric mounting stud, 10-32 to M5 x 0.80 long (1)
OPTIONAL ACCESSORIES:
Model 073A16 DC switching power supply (for Model 394C06) (1)
Model 080A150 Mounting Base (1/4-28) (1)
Model 080B44 3
-
Pin Mounting Adapter (1)
Entered: AP Engineer: AJP Sales: WDC
Approved: JWH
Spec Number:
Date: 1/28/2013 Date: 1/28/2013 Date: 1/28/2013 Date: 1/28/2013
1345
