A A
B B
CODE
IDENT. NO.
52681
DWG. NO.
SCALE: SHEET
DRAWN CHECKED ENGINEER
TITLE
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
ANGLES 2 DEGREES
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DIMENSIONS IN INCHES
ANGLES 2 DEGREES
FILLETS AND RADII
.003 - .005
FILLETS AND RADII
0.07 - 0.13
OUTLINE DRAWING
48297
1 OF 1
FULL
MODEL 682M57
AMPLIFIER
DECIMALS XX ±.03
XXX ±.010
DECIMALS X ± 0.8
XX ± 0.25
BB
01/29/15
ECB
01/29/15
GS
01/29/15
5
6
7
8
9
10
11
12
-
SIG
SHLD
SHLD
+
SIG
+
VDC
N/C
N/C
COM
5
6
7
9
9
10 11 12
REVISIONS
REV DESCRIPTION DIN
A REMOVED CONTROL BLOCK 43742
1.) HOUSING MATERIAL: INJECTION MOLDED NYLON 66 (POLYAMIDE) RATED UL 94-V0.
4
8
2
9
7
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
.26 [6.6].89 [22.6]4.5 [114]
3.90 [99.0]
Terminal Connection
5 -SIG IN 9 + POWER VDC
6 SHIELD 10 N/C
7 SHIELD 11 N/C
8 +SIG IN 12 COMMON
DIFFERENTIAL
CHARGE AMPLIFIER
MODEL: 682M57
