Pco Edge 3.1 User Manual

39
6 CAMWARE 4 SOFTWARE
6
7
6.4 IMAGE OVERLAY
Open Image Overlay: you can easily switch between Camera
Properties and Image Overlay with these two buttons.
If not available, please see Fehler! Verweisquelle konnte nicht
gefunden werden. View Menu to activate this menu.
This function enables an individually configurable image overlay
allowing to display information within the images.
Many different options are available by clicking Add item to…
Also the Appearance is configurable:
Font, Text color, Text opacity, Background color, Background
opacity and horizontal or vertical orientation.
Camera image number and Camware Image Number are two
different count methods:
Camera image number: the image numbers are being incremented
continuously. When recording in Ring Buffer mode, the image
numbers are exceeding the number of images being stored in the
RAM memory of the camera since images are being overwritten
when the memory is full.
Camware image number: the software displays the image numbers
according to the number of images being recorded (starting with
image 1).
A preview of the image overlay is shown.
Each item can be moved upwards, downwards or deleted by clicking
on …
By drag & drop the Image Overlay can be moved easily to your
favorite position within an image.
To activate image overlay right-click in the image
window and activate Show Image Overlay.
1
2
2
5
6
5
7
1
NOTE
This function does not overwrite image data.
3
4
3
4
