A1 TECHNICAL DATA
A1.1 DATA SHEET
Image sensor
pco.edge 4.2 bi (UV)
Type of sensor
Customized sCMOS
Resolution (h x v)
2048 x 2048 pixel
Pixel size (h x v)
6.5 μm x 6.5 μm
Sensor format / diagonal
13.3 x 13.3 mm / 18.8 mm
Shutter mode
Rolling Shutter (RS)
MTF
76.9 lp/mm (theoretical)
Camera
Frame rate
40 fps @ full resolution
Exposure / shutter time
10 μs ... 20 s
Dynamic range A/D
16 bit
Binning (h x v)
1x1 ... 4x4
Cooling method
Adjustable: from -25°C to +20°C
Peltier with forced air (fan) and water cooling.
Calibration setpoint: -10°C
Trigger input signals
Frame Trigger, Acquire (SMA connectors)
Trigger output signals
Exposure, Busy (SMA connectors)
Data interface
USB 3.1 Gen1
Timestamp
In image (1 μs resolution)
General
Power delivery
Power over USB 3.1 Gen1 Type-C and power
connector (24 VDC +/- 10%)
Power consumption
Typ. 4.5 W over USB 3.1 Gen 1 and
typ. 10.0 W (max. 22.0 W) over power
connector
Weight
920 g
Operating temperature
+10°C ... +40°C
Operating humidity range
10% ... 80% (non-condensing)
Storing temperature
range
-10°C ... +60°C
Optical interface
F-mount, C-mount
CE / FCC certified
Yes
ROI step sizes
Horizontal steps
32 pixel steps
Vertical steps
8 pixel steps
Minimum ROI
64 x 16 pixels
Subject to change, refer to current data sheet available on our website.
