29
6.4 IMAGE OVERLAY
Open Image Overlay: these buttons allow easy switching between
Camera Properties and Image Overlay windows.
If not available, see 6.9.5 View Menu to activate this menu.
This function enables an individually configurable image overlay, to
display information within the images.
Many options are available by clicking Add Item to List
Also the Appearance is configurable:
Font, Text Color, Text Opacity, Background Color, Background
Opacity and X Position or Y Position.
Camera Image Number and Camware Image Number are
two different count methods:
Camera Image Number: the image numbers are being incremented
continuously. When recording in Ring Buffer mode, the image
numbers are exceeding the number of images being stored in the
RAM memory of the camera since images are being overwritten
when the memory is full.
Camware Image Number: the software displays the image
numbers according to the number of images being recorded (starting
with image 1).
Preview of the Image Overlay.
Each item can be moved or deleted: Move Upwards, Move
Downwards or Delete by clicking on …
Move the Image Overlay to your favorite position by drag & drop.
Right-click in the image window to activate Show
Image Overlay.
In contrast to Timestamp, this function does not
overwrite image data.
