36
6.8.1 AUTO SAVE
Auto Save helps to save recorded images or sequences in an easy
way. There is no need to save each image / sequence separately
from each connected camera. Therefore this function is very useful if
you use more than one camera. Once configured Auto Save allows
acquiring and saving as many images / sequences as needed during
your experiment. This function stores RAW (e.g. b16, TIFF) and
Export (compressed e.g. AVI, JPG) files.
Standard file save see File menu 6.9.2.
Explanations are shown in the info text window at the bottom of the
menu.
Enable Auto Save by clicking on the check box.
The text changes to Unconfigured! (red
background).
Right-click on the Unconfigured! field and click on
Configure ‘Auto Save’. The Auto Save Options
dialog is displayed.
General Auto Save Settings
Global
Auto Save Mode: three
different modes are
available, Save manually
and two variants of Save
unattendedly.
The Save manually mode allows to store RAW images and export
images after a recording session, when hitting the ALT and D keys.
This allows to cut the image sequence in the Recorder Toolbar
before saving.
The Save unattendedly mode enables to download all RAW images
and to export the complete image sequences of all cameras
immediately after an active recording is stopped.
Save unattendely (automatic start after record): saves all image
data after recording is stopped.
Save unattendely (automatic start after record) and restart
recording: after a recording has been saved, Auto Save restarts the
recording, and then saves again – endlessly.
Select Output:
Off: Auto Save is deactivated
Save RAW: only 16 bit RAW files are stored
(b16, PCORAaw-File, MultiTif-File, tiff)
Export: only compressed files are stored (bmp,
jpg, tiff, avi, mpeg, wmv)
Save RAW and Export: RAW and compressed
files are stored simultaneously
