GENERAL rev. 2020/04
Seating Capacity 7
Shell Material Acrylic
Dimensions (Domestic) 82” (6’10”) sq. x 39” (3’3”)
Dimensions (Export) 209cm. sq. x 100 cm.
Water Capacity 425 Gallons (1,609 liters)
Dry Weight 645 lbs. (293 kg)
Skirt Material PermaWood™
Water Flow 428 Gallons per Minute
SPECIAL FEATURES
Spa Pillows
Water Spout Control Valve C
Cascading Spouts WS
Stainless Steel Jetting
Prism LED™ Light
SoundStream™ Audio
Ozone Water Purification
2
Standard
Standard
Standard
Optional*
Standard
Standard
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 4.0 (2.0) HP 4.0 (2.0) HP
Pump #2 peak (continuous) HP 2 4.0 (2.0) HP 4.0 (2.0) HP
Electronics
Electrical Can 6 Balboa 100X1 in.kYE 3 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 ProView™ in.k500 Series
WATER SYSTEM** (photo ref.)
7
G
A
I
G
A
E
E
U
V
LE
LE
LE
E
O
U
U
L
G
A
WS
G
I
V
E
I
C
LE
1
2
U
I
G
A
G
O
5
OZ 6, H
Ozonator Water Treatment System OZ
25 sq. ft. Filter, PowerFlo™ System
4 Slide Valves
3 MegaSwirl™ Jet A
41 Euro Jet w/eyeball E
14 Mega’assage™ Jet G
2 Ozone Jet O
3 Large Euro Jet LE
2 Diverter Valves V
4 Safety Suction U
1 Mini Skimmer K
4 Air Control I
1 Spa Light L
1 Drain Valve 5
12”
14”
wire feed
