Checking the Spark Plug:
A spark plug with dirty/corroded electrodes or an excessive gap between
electrodes will not be able to generate an effective spark.
Cleaning - Use a propriety plug cleaner or use a fi ne wire brush to clean the
electrodes.
Adjusting - The gap between electrodes should normally be within 0.6 to
0.7mm.
IMPORTANT, do not use a screwdriver between the electrodes to adjust
the gap this can break the insulation around the centre electrode - adjust
using the correct tool or a pair of needle nose pliers.
Recommended spark plug - NGK
CAUTION: - Avoid burning yourself when working on a hot engine.
When replacing a spark plug, screw into place by hand fi rst and then
tighten with a socket wrench (do not over tighten).
10
1 3
5
2
4
Instrument Panel and warning lights
All the necessary visual indications are shown on the instrument panel:
1. Fuel Guage
2. Speedometer
3. Odometer
4. High Beam Indicator
5. Turn Indicator
Fuel Gauge:
The fuel gauge indicates the approximate amount of fuel remaining in
the fuel tank. When the needle pointer stays in the F (full) position, it
means the total capacity of the tank is 6.0 litres (including reserve). When
the needle pointer approaches the  rst dot on the red marker, it means
the fuel tank should be re lled immediately.
