3
2013-09-16 #:145-9028-4 (2013-10-31)
Symbols
WARNING
x3
Screws must get
at least three full
turns and t snug.
Do not overtighten screws.
To properly tighten screws: Tighten until screw head
makes contact, then tighten another 1/2 turn. Do not
overtighten screws.
1
2
+1/2
4
3
Tools Needed for Assembly.
5/16"
(8mm)
Before installing make sure the supporting surface will support the combined load of the equipment and
hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift
and position equipment. This product is intended for indoor use only. Use of this product outdoors could lead to
product failure or personal injury. Be careful not to pinch ngers when operating the mount. For support please
call customer care at 1-800-865-2112.
WARNING
