peerless-AV ESHV30 - Product Parts List and Identification

6
2011-01-21 #:083-9014-3 (2018-02-26)
Parts (Before beginning, make sure you have all parts shown below).
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes).
Pièces (avant de commencer, assurez-vous d’avoir toutes les pièces illustrées ci-dessous).
Teile (Achten Sie vor Beginn der Arbeiten darauf, dass alle unten abgebildeten Teile vorhanden sind).
Onderdelen (hoort u zich ervan te overtuigen dat u alle onderdelen hebt, die hieronder te zien zijn).
Parti (prima di iniziare, accertarsi di disporre tutte le parti sotto indicate).
Díly (předtím, než začnete, připravte si všechny díly zobrazené níže).
Diely (predtým, ako začnete, pripravte si všetky diely zobrazené nižšie).
Peças (antes de iniciar, certique-se de que tem todas as peças apresentadas em baixo).
Parçalar (Başlamadan önce, aşağıda gösterilen bütün parçaların elinizde olduğundan emin olun).
ENG
ESP
FRN
DEU
NEL
ITL
ČEŠ
SLK
POR
TÜR
Parts List
Description Qty
A column 2
B shelf attachment clamp 2
C M5 x 44mm wood screw 4
D concrete anchor 4
E M5 x 18mm socket cap screw 4
F M5 x 12mm socket cap screw 2
G glass support bracket 2
H screw cover 4
I M5 washer 6
J shelf bracket 2
K glass shelf 2
L support clip 8
M 4mm allen wrench 1
N 2.5mm allen wrench 1
O column connector 1
B (2)
shelf attachment clamp
M5 x 44mm
wood screw
concrete
anchor
M5 x 18mm
socket cap screw
screw cover
support clip
column connector
glass shelf
M5 washer shelf bracket
M5 x 12mm
socket cap screw
glass support
bracket
A (2)
column
I (6)
E (4)D (4) F (2)C (4) G (2)
H (4)
O (1)
K (2)
J (2)
L (8)
4mm allen wrench
2.5mm allen wrench
N (1)
M (1)
