LCT420A LCT620A
Description
Qt
y
Qt
y
A column assembly 1 1
B single link arm assembly 1 -
double link arm assembly - 1
C grommet assembly 1 1
D round rubber pads 2 2
E square rubber pads
2
2
F M4 x 12 mm phillips screw
4
4
G M4 x 30 mm phillips screw
44
H M5 x 12 mm phillips screw
44
I M5 x 30 mm phillips screw
44
J spacer 4
4
K 4 mm allen wrench 1
1
L 2.5 mm allen wrench 1
1
M cable clip
11
N cable tie
55
Parts List
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included
with your product.
L
K
A
C
D
E
FHGIJ
MN
B
LCT420A LCT620A
OR
