A. GENERAL
1. Pinnacle Oil boilers are supplied factory assembled
with pressure vessel, base, and jacket panels. A trim
box containing the relief valve, drain valve,
temperature / pressure gauge and associated pipe
fittings is included in the crate.
2. The burner, acoustic shroud and venting are shipped
separately for field assembly. The POC control is
shipped separately for maximum flexibility.
3. The package should be carefully inspected for damage
upon receipt and any damage to the unit should be
reported to the shipping company and wholesale
distributor.
4. The boiler should be stored in a clean, dry location.
5. Carefully read these instructions and be sure to
understand the functions of all mechanical and
electrical connections before beginning the
installation. Contact your PB Heat, LLC
representative for help in answering questions.
6. This boiler must be installed by a qualified contractor.
The boiler warranty may be voided if the boiler is not
installed correctly.
7. This boiler may be installed at high altitudes above
5,000 feet elevation. Consult burner manual
(included) for burner requirements.
B. CODES & REGULATIONS
1. Installation and repairs are to be performed in strict
accordance with the requirements of state and local
regulating agencies and codes dealing with boiler and
appliance installation.
2. In absence of local requirements the following codes
and standards should be followed.
a) ASME Boiler & Pressure Vessel Code, Section IV –
Heating Boilers
b) ASME Boiler & Pressure Vessel Code, Section VI –
Recommended Rules for the Care and Operation
of Heating Boilers.
c) ANSI/NFPA 70 – National Electrical Code
d) NFPA 31 – Standard for the Installation of Oil-
Burning Equipment.
e) ANSI/NFPA 211 – Chimneys, Fireplaces, Vents
and Solid Fuel Burning Appliances.
3. Where required by the authority having jurisdiction,
the installation of this equipment must comply with
ANSI/ASME CSD-1 – Standard for Controls and
Safety Devices for Automatically Fired Boilers.
C. ACCESSIBILITY CLEARANCES
1. The Pinnacle Oil boiler is design certified for closet
installations with zero clearance to combustible
construction. In addition, it is certified for use on
combustible floors provided the boiler is not installed
on carpeting.
2. Refer to Figure 1.1 for the recommended clearances
to allow for reasonable access to the boiler. Local
codes or special conditions may require greater
clearances.
D. COMBUSTION & VENTILATION AIR
1. The Pinnacle Oil boiler is designed for several options
for combustion air and venting.
a) Concentric Sidewall Venting
b) Concentric Vertical Chimney Venting
c) Single Wall Vertical Chimney Venting using the
chimney as a chase for inlet air.
d) Concentric Vertical Roof Venting
2. The concentric venting options are designed for
operation with combustion air piped from the outside
(sealed combustion). For these options, no additional
ventilation air is required.
PREINSTALLATION
1. PREINSTALLATION
This appliance must be supplied with adequate
combustion air to properly burn the fuel. Failure to
supply an adequate air supply will result in
incomplete combustion resulting in sooting and
carbon monoxide emission. This may result in severe
personal injury, death or major property damage.
WARNING
DANGER
Do not install this boiler on carpeting.
