4
A. GENERAL
1. Pinnacle Oil boilers are to be installed in either an
area with a floor drain or in a suitable drain pan.
Do not install any boiler where leaks or relief valve
discharge will cause property damage.
2. This boiler is not intended to support external piping.
All venting and other piping should be supported
independently of the boiler.
3. Provide a level foundation, located as close as
practicable to the center of the heating system.
4. After removing the boiler from the packaging and
setting it on its foundation, open the burner swing
door on the top of the boiler and make sure the jet
inserts are seated properly in the combustion
chamber. Refer to the repair parts in Section 11 to
identify these parts. Close the burner swing door
before continuing.
5. Install the boiler level to prevent condensation from
blocking the vent system.
BOILER SET-UP
2. BOILER SET-UP
Be sure that any packing material that is in the
combustion chamber to protect the Jet Inserts is
removed before firing the appliance. Failure to do
this may result in minor personal injury or property
damage.
CAUTION
