16
BURNER SETUP & BOILER OPERATION
CARLIN BURNER SPECIFICATIONS
Boiler
Model No.
Firing Rate
Burner
Model No.
Air
Shutter
Nozzle Size
Pump
Pressure
Start-up Settings
Air Band
Head Bar
EC/ECT-03-075 .75 EZ-1HP Blank 0.60 70° B DEL³ 150 psig 0.55 0.60 - 0.65
EC/ECT-03-100 1.00 EZ-1HP Blank 0.85 70° A DEL 150 psig 0.65 0.85 - 1.00
EC/ECT-03-120 1.20 EZ-1HP Blank 1.00 70° A DEL³ 150 psig 0.80 0.85 - 1.00
Boiler
Model No.
Burner
Model No.
Air
Shutter
Nozzle Size
Pump
Pressure
Start-up Settings
Head Dim. A Air Band
EC/ECT-04-125 99FRD Blank 1.00 x 70° B DEL³ 150 psig 2 40% open
EC/ECT-04-150 99FRD Blank 1.25 x 60° B DEL³ 150 psig 3 60% open
EC/ECT-04-175 99FRD Blank 1.50 x 60° B DEL 150 psig 4 100% open
EC/ECT-05-175 99FRD Open 1.50 x 60° B HAGO³ 150 psig 5 10% open
EC/ECT-05-200 99FRD Open 1.65 x 60° B HAGO 150 psig 5 45% open
EC/ECT-05-250 99FRD Open 2.00 x 60° B HAGO³ 150 psig 8 100% open
EC/ECT-06-275 102CRD Open 2.25 x 60° B DEL³ 150 psig 6 100% open
EC/ECT-06-300 102CRD Open 2.50 x 60° B DEL 150 psig 8 100% open
BECKETT BURNER SPECIFICATIONS (140 psig Pump Pressure)
Boiler
Model No.
Burner
Model No.
Burner Head Static Plate Nozzle Size
Start-up Settings
Head Setting
Air Shutter Air Band
EC/ECT-03-075 AFG-L1¹ L1¹ 3-3/8" 0.65 60° B HAGO³ 9.0 2 N/A
EC/ECT-03-100 AFG-L1 L1 3-3/8" 0.85 60° B HAGO 10.0 1 N/A
EC/ECT-03-120 AFG-L1 L1 —² 1.00 60° B HAGO³ 9.0 2 N/A
EC/ECT-04-125 AFG-F6 F6 2-3/4" 1.10 80° A DEL³ 5.0 1 N/A
EC/ECT-04-150 AFG-F6 F6 2-3/4" 1.25 80° B HAGO 8.0 1 N/A
EC/ECT-04-175 AFG-F6 F6 2-3/4" 1.50 80° B HAGO³ 10.0 3 N/A
EC/ECT-05-175 AFG-MV1 M-V1-3 — 1.50 60° B HAGO³ 10.0 3 3
EC/ECT-05-200 AFG-MV1 M-V1-3 — 1.75 60° B HAGO 10.0 9 3
EC/ECT-05-250 AFG-MV1 M-V1-5 — 2.00 45° B HAGO³ 10.0 5 5
EC/ECT-06-275 CF-375 L1-S — 2.25 45° P HAGO³ 10.0 6 2
EC/ECT-06-300 CF-375 L1-S — 2.50 45° P HAGO 10.0 6 3
RIELLO BURNER SPECIFICATIONS
Boiler
Model No.
Firing Rate
Burner
Model No.
Nozzle Size Pump Pressure
Start-Up Settings
Turbulator Air Damper
EC/ECT-03-075 .75 F5 0.60 60° B DEL³ 155 psig 0.5 2.1
EC/ECT-03-100 1.00 F5 0.85 60° W DEL³ 145 psig 2.0 2.6
EC/ECT-03-120 1.20 F5 1.00 60° W DEL 145 psig 3.0 2.9
EC/ECT-04-125 1.25 F5 1.00 60° W DEL 155 psig 2.5 3.4
EC/ECT-04-150 1.50 F10 1.25 60° B DEL³ 145 psig 1.5 3.1
EC/ECT-04-175 1.75 F10 1.35 60° B DEL 165 psig 2.0 2.5
EC/ECT-05-175 1.75 F10 1.35 60° B DEL³ 165 psig 2.0 2.5
EC/ECT-05-200 2.00 F10 1.50 60° B DEL 170 psig 2.5 2.8
EC/ECT-05-250 2.50 F10 2.00 60° B DEL³ 155 psig 3.5 4.2
EC/ECT-06-275 2.75 F10 2.25 60° B DEL³ 150 psig 4.0 4.2
EC/ECT-06-300 3.00 F10 2.50 60°B DEL 145 psig 4.5 4.2
Table 5.1: Carlin Burner Specifications
Table 5.2: Beckett Burner Specifications
Table 5.3: Riello Burner Specifications
Factory Installed Nozzles (Packaged Boilers or Burner Cartons) are indicated in Boldface.
1 Requires Low Firing Rate Baffle
2 Remove Static Plate for 1.20 GPH Rate
3 Shipped Loose with Packaged Boiler or Burner Carton
