Pegasus PUA-310 - Connection to Other Controllers

2. If you connect PUA-310 with other controller , please refer to below
connecting description.
Wire No Colour Function
1 Red +12VDC
2 Black Ground
3 Green Data0
4 White Data 1
5 Shield/Ground Shield/Ground
Specifications subject to change without notice for further modification.
y OUTLOOKING
Template Front view
W-04-PUA310/E
