Insulated Enclosure
Lock Screw
Connecting Procedures:
1. Tighten the lock screws on positive and cathode connector.
2. Use specied strip tool to strip the insulated enclosure of the positive and
cathode cables with appropriate length.
Positive Cable
L
1
L
1
L
2
=8-10mm
L
2
=8-10mm
Negative Cable
NOTICE
• Please place the connector separately after unpacking in
order to avoid confusion for connection of cables.
• Please connect the positive connector to the positive side of
the solar panels, and connect the cathode connector to the
cathode side of the solar side. Be sure to connect them in
right position.
To Next Page
