Peka Magic Corner II - Frame Overlay Installation; Dimensions and Swing Direction

4/13950.0359.MA
Peka
DE Front aufschlagend
FR Devant le cadre
EN Frame overlay
min. 500 (20“)
485 (19“)
485 (19“)
416 (16
3/8“
)
288 (11
21/64“
)
160 (6
5/16“
)
64 (2
1/2“
)
32 (
1/4“
)
504 (19 27/32“)
962-1171 (37
7/8“
-46
7/64“
)
max. 25,4 (1“)
+1 - 0
488 (19 7/32“)
481 (18
15/16“)
481 (18
15/16“)
47 (1
55/64“)
47 (1
27/32“)
+1 - 0
518 (20
25/64“
)
Spacer min. 60 (2
23/64“)
min. 553 (21 49/64“)
min. 494 (19
29/64“
)
DE Masse in mm, Inches
sind ungefähre Werte.
FR Les dimensions en mm,
en pouces sont des valeurs
approximatives.
EN Dimensions are in mm;
values in inches are
approximate.
DE Links ausschwenkbar dargestellt. Rechte
ausschwenkbare Variante spiegelbildlich anwendbar.
FR Représenté pour un pivotement à gauche.
Variante de pivotement à droite, croquis miroir.
EN This diagram is for a system that swings out to the left.
For systems that swing out to the right, use the same
measurements, but on the other side.
44 (1
47/64“
)
92 (3 7/32“)
31 (1
7/32“
)
79 (3
7/64“
)
51 (2“)
35 (1
3/8“
)
19 (
3/4“
)
213 (8
3/8“
)
229 (9
1/64“
)
245 (9
41/64“
)
1
