Peka Magic Corner II - Frameless Cabinet Installation; Dimensions and Swing Direction

6/13950.0359.MA
Peka
min. 553 (21 49/64“)
min. 494 (19
29/64“
)
min. 500 (20“)
485 (19“)
485 (19“)
416 (16
3/8“
)
288 (11
21/64“
)
160 (6
5/16“
)
64 (2
1/2“
)
32 (
1/4“)
504 (19 27/32“)
962-1171 (37
7/8“
-46
7/64“
)
+1 - 0
488 (19 7/32“)
481 (18
15/16“)
481 (18
15/16“)
47 (1
55/64“)
47 (1
27/32“)
+1 - 0
DE Links ausschwenkbar dargestellt. Rechte
ausschwenkbare Variante spiegelbildlich anwendbar.
FR Représenté pour un pivotement à gauche.
Variante de pivotement à droite, croquis miroir.
EN This diagram is for a system that swings out to the left.
For systems that swing out to the right, use the same
measurements, but on the other side.
DE Standard Möbel (Front)
FR Meuble standard (pas de cadre)
EN Frameless
DE Masse in mm, Inches
sind ungefähre Werte.
FR Les dimensions en mm,
en pouces sont des valeurs
approximatives.
EN Dimensions are in mm;
values in inches are
approximate.
44 (1
47/64“
)
92 (3
7/32“
)
31 (1
7/32“
)
79 (3
7/64“
)
51 (2“)
35 (1
3/8“
)
19 (
3/4“
)
213 (8
3/8“
)
229 (9
1/64“
)
245 (9
41/64“
)
1
