8 Pelco Manual C527M (11/97)
4.0 SPECIFICATIONS
Keyboard Keypad: Mechanical
Joystick: 3 axis, vector solving, with twisting return-to-center head
7-Segment
Digital Display: Red LED, 2 cells
Shift Mode
Indicator: Green LED
Electrical
Input voltage: 12 VAC or ±12 VDC
Power
Consumption: 1 watt
Ambient
Operating
Temperature: 20° to 120° F (-7° to 49° C)
Humidity: 10% - 90% non-condensing
Connector Type: RJ-45 8-pin modular (female)
Keyboard Communication
Protocol: RS-485
Baud Rate: 9600
General
Dimensions: 9.50" x 7.125" x 2.25" (24.13 cm x 18.1 cm x 5.72 cm)
Weight: 2.5 lbs (1.12 kg)
(Design and product specifications subject to change without notice.)
