Atttach the chip (8) to the simulator body and move with it as shown, then switch the laser
on.
LED (9) should flash blue should sound. The number of flashes indicate the battery status:
• 5 flashes – the battery is 100% full
• 4 flashes – the battery is at 75% charge level
• 3 flashes – the battery is at 50% charge level
• 2 flashes – the battery is at 25% charge level
• 1 flash – the battery is empty, change it.
• The LED flashing continuously blue means the battery is empty and the battery
should be changed immediately.
After the battery test run, the LED light remains constantly blue to indicate the laser is on.
The laser container will switch off approx. 20 minutes after the last shot.
GLS17 laser simulator setting – laser dot setting
Check zeroing with a shot on a white wall from a distance of 10 meters. You should see a red
dot impact. Use the adjusting screws to set the laser dot:
• Turning the screw (10a) clockwise – laser dot goes to the left
• Turning the screw (10a) counterclockwise – laser dot goes to the right
