Left Pedal
Right Pedal
Left Crank Arm
Right Crank Arm
Mounting Collar
Shaft
Propeller
Mounting Bracket
Tethered Mounting Bolt
Mounting Bolt Knob
Quick Key
Prop Alignment Marks (4)
Pedal Drive Head Unit
2
